ACER Extensa EX215-54-31GM RAM upgrade specifications
The ACER Extensa Series 15 model EX215-54-31GM supports DDR4-SDRAM memory upgrades. The laptop features one SO-DIMM slot for RAM expansion, with a maximum upgrade capacity of 12 GB. Compatible memory operates at 2133 MHz frequency. The system includes on-board memory combined with the expandable SO-DIMM slot configuration. Specifications indicate the upgrade slot accommodates standard SO-DIMM form factor modules. Maximum RAM capacity of 12 GB represents the total supported memory for the EX215-54-31GM model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 1x SO-DIMM |
| Form factor | On-board + SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2133 MHz |
| Maximum RAM | 12 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2133 (PC4-17064) |
| Bandwidth | 17.1 GB/s |
| Laptop Release date | 10 April 2021 |
Additional Notes
- The presence of a single SO-DIMM slot alongside permanent on-board memory means that total capacity increases require replacing the existing module rather than adding a second one.
- The ACER Extensa EX215-54-31GM architecture dictates a maximum expansion limit of 8 GB for the removable module to reach the 12 GB ceiling.
- Installing modules with frequencies higher than 2133 MHz will result in automatic downclocking to match the system bus speed.
- Asynchronous dual-channel mode will only function for the capacity portion where the on-board and removable memory sizes match, while the remaining capacity operates in single-channel mode.
- Integrated memory chips are non-serviceable and cannot be replaced or upgraded in the event of hardware failure.
- Accessing the SO-DIMM slot requires the removal of the entire base panel which may involve piercing factory seals depending on regional warranty policies.
- Physical clearance within the chassis restricts compatibility to standard height SO-DIMM modules and precludes the use of thick heat spreaders.
