ASUS ROG G615LP-XS97 RAM upgrade specifications
ASUS ROG Strix G16 G615LP-XS97 laptop features DDR5-SDRAM memory upgrade capabilities with two SO-DIMM slots supporting maximum 64 GB capacity. Compatible memory modules operate at 5600 MHz frequency. Specifications indicate SO-DIMM form factor for both upgrade slots, enabling users to expand total system memory up to the maximum supported capacity of 64 GB through compatible DDR5 memory modules.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 5600 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-5600 (PC5-44800) |
| Bandwidth | 44.8 GB/s |
Additional Notes
- Dual channel architecture requires matching memory modules in both slots to maximize the available 128 bit memory bus bandwidth.
- The ASUS ROG G615LP-XS97 motherboard chipset architecture imposes a 32 GB limit per individual slot to reach the specified capacity threshold.
- Installing modules with differing speeds results in the system downclocking all memory to the lowest common frequency supported by the processor memory controller.
- The use of SODIMM modules necessitates careful cable management during installation as these slots are typically positioned deep within the thermal assembly.
- Upgrading to the maximum capacity may increase internal heat generation and slightly shorten battery runtime due to higher power draw on the voltage regulator modules.
- Physical access to the dual slots usually requires the removal of the bottom chassis panel which may involve navigating delicate ribbon cables for internal lighting.
- Latency performance depends on the integrated memory controller within the CPU as DDR5 utilizes on-die Error Correction Code for enhanced stability during high load tasks.
