ASUS ROG G733CX-LL045W RAM upgrade specifications
ASUS ROG Strix SCAR 17 G733CX-LL045W laptop specifications indicate DDR5-SDRAM memory upgrade capacity of 64 GB maximum. The system contains 2x SO-DIMM slots for RAM expansion. Compatible memory modules operate at 4800 MHz frequency using SO-DIMM form factor. Specifications support dual-channel memory configuration for optimized performance on the gaming-oriented ROG platform.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
| Laptop Release date | 29 June 2022 |
Additional Notes
- The dual slot configuration allows for a symmetrical dual channel architecture which doubles the available memory bandwidth compared to single channel setups.
- Upgrading the ASUS ROG G733CX-LL045W to the maximum capacity requires the removal of all existing modules because no vacant slots are available for expansion.
- The presence of SO-DIMM slots implies that the memory is not soldered to the mainboard and remains fully replaceable for maintenance or performance tuning.
- Installing modules with speeds exceeding 4800 MHz will result in the hardware downclocking to the system bus limit to maintain stability.
- Higher density 32 GB modules must be unbuffered and non-ECC to ensure motherboard compatibility and successful POST cycles.
- Accessing the internal memory sockets requires careful removal of the bottom chassis panel which may involve navigating delicate ribbon cables for integrated lighting components.
- Mixing different brands or latencies between the 2 slots can trigger a fallback to the highest common timing profile and potentially increase system latency.
