ASUS ROG GX703HR-K4013T RAM upgrade specifications
ASUS ROG Zephyrus S17 model GX703HR-K4013T supports DDR4-SDRAM memory upgrade through one SO-DIMM slot. The laptop features on-board memory combined with a single upgradeable SO-DIMM slot, allowing maximum RAM capacity of 48 GB. Compatible memory operates at 3200 MHz frequency. RAM specifications enable users to expand memory capacity by installing compatible DDR4 modules in the available slot to enhance system performance and multitasking capabilities.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 1x SO-DIMM |
| Form factor | On-board + SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 48 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 24 May 2021 |
Additional Notes
- The ASUS ROG GX703HR-K4013T contains soldered on-board memory paired with a single SO-DIMM slot, meaning only 1 memory module can be added or replaced after purchase.
- Total addressable memory reaches 48 GB when the SO-DIMM slot is populated at maximum capacity, indicating a fixed on-board allocation of either 16 GB or 32 GB depending on configuration variant.
- SO-DIMM modules operate at 3200 MHz, establishing a strict bandwidth ceiling for any replacement or upgrade memory that must match this frequency to avoid throttling or instability.
- Soldered memory cannot be removed without desoldering equipment, making the on-board portion permanent for the device lifecycle and effectively non-upgradeable through standard user replacement procedures.
- Only DDR4-SDRAM modules in SO-DIMM form factor will function in the available slot; DDR5 or alternative memory standards cannot be retrofitted regardless of future availability.
- Adding or replacing the single SO-DIMM represents the only warranty-safe memory upgrade path, as opening the chassis to access this slot typically voids coverage depending on regional ASUS service policies.
- Asymmetric memory configuration (soldered plus modular) may result in dual-channel operation only when the SO-DIMM capacity matches or exceeds the on-board allocation, affecting memory bandwidth efficiency.
