ASUS TUF Gaming FA706QM-HX008W RAM upgrade specifications
ASUS TUF Gaming A17 FA706QM-HX008W laptop features two SO-DIMM slots for memory upgrade capability. Compatible RAM specifications include DDR4-SDRAM operating at 3200 MHz frequency. Maximum supported memory capacity reaches 32 GB total. Upgrade options accommodate SO-DIMM form factor modules. Current and additional memory modules must meet DDR4 specifications for proper compatibility with this gaming laptop model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 08 January 2022 |
Additional Notes
- Dual channel mode functionality requires identical capacity and frequency across both physical slots to minimize memory controller latency.
- The maximum supported capacity necessitates the removal of existing modules as no additional vacant slots exist for expansion.
- BIOS limitations restrict the memory frequency to 3200 MHz even if higher rated modules are installed for the ASUS TUF Gaming FA706QM-HX008W.
- Integrating high density 16 GB modules per slot is the only method to reach the total system ceiling due to the lack of specialized motherboard traces for 4 slot configurations.
- Upgrading memory requires non conductive tools to prevent short circuits on the motherboard since the battery remains physically connected during initial access.
- Standard height SO-DIMM modules are required to ensure the base cover fits without causing physical pressure on the integrated circuits or thermal pads.
- Installation of XMP profiles is generally unsupported by the firmware resulting in the hardware defaulting to standard JEDEC timings for stability.
