ASUS Vivobook TP412FA-EC425T RAM upgrade specifications
The ASUS Vivobook Flip TP412FA-EC425T supports DDR4-SDRAM memory upgrades with a maximum capacity of 16 GB. The laptop features one SO-DIMM slot for RAM expansion, compatible with 2400 MHz modules. The memory specifications include on-board components plus one removable SO-DIMM slot, enabling users to upgrade the system memory configuration on this ASUS Vivobook Flip series model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 1x SO-DIMM |
| Form factor | On-board + SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2400 MHz |
| Maximum RAM | 16 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2400 (PC4-19200) |
| Bandwidth | 19.2 GB/s |
| Laptop Release date | 23 December 2019 |
Additional Notes
- The presence of on board memory means a portion of the system RAM is non replaceable and permanently soldered to the motherboard.
- The single SO DIMM slot restricts the ASUS Vivobook TP412FA-EC425T to a single channel upgrade path for the removable module.
- Dual channel performance benefits rely on matching the capacity of the added module to the existing soldered memory.
- Total system capacity is limited by the physical constraint of having only 1 expansion interface available for high density modules.
- Mixing modules with different timings will force the system to default to the highest common latency profile supported by both the soldered and socketed chips.
- Installation of a module exceeding the 16 GB threshold will result in a failure to boot or memory addressing errors at the BIOS level.
- Choosing a module with a frequency higher than 2400 MHz will result in automatic downclocking to match the hardcoded limit of the chipset.
- Internal access for hardware modification requires the removal of the lower chassis assembly which may involve hidden screws beneath rubber feet.
