DELL Inspiron 5418 RAM upgrade specifications
The Dell Inspiron 5000 Series 5418 laptop features DDR4-SDRAM memory upgrade specifications with two SO-DIMM slots supporting a maximum RAM capacity of 32 GB. Memory modules operate at 3200 MHz frequency and utilize the SO-DIMM form factor, compatible with standard DDR4 specifications. Upgrade options allow users to configure the system with compatible memory modules up to the maximum supported capacity for enhanced multitasking and performance capabilities.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 16 May 2021 |
Additional Notes
- Dual channel architecture in the DELL Inspiron 5418 requires symmetrical module capacities to optimize memory bandwidth and reduce system latency during intensive multitasking.
- The maximum capacity limit indicates a hardware cap on high density 16 GB modules per slot which prevents the use of 32 GB single sticks.
- Utilizing memory modules with speeds exceeding 3200 MHz results in automatic downclocking to match the integrated memory controller hardware limitations.
- Total memory replacement is necessary for upgrades if both factory slots are occupied because there are no soldered memory components to serve as a base capacity.
- Thermal management remains a factor during installation as the SO DIMM slots are positioned in close proximity to other heat generating internal components.
- Compatibility is restricted to non ECC unbuffered modules as the chipset does not support error correction code memory for server grade data integrity.
- Physical access to the memory slots requires removal of the bottom chassis cover which involves navigating internal plastic clips that are sensitive to mechanical stress.
