HP ENVY 13-ba0007tx RAM upgrade specifications
HP ENVY 13-ba0007tx RAM upgrade specifications indicate DDR4-SDRAM memory compatibility with a single SO-DIMM slot. The compatible RAM upgrade supports maximum memory capacity of 8 GB at 2666 MHz frequency. The laptop features one memory slot for DDR4 SO-DIMM modules. Specifications confirm the HP ENVY 13 series 13-ba0007tx model accepts compatible DDR4-SDRAM upgrades up to 8 GB total capacity. Memory slot configuration allows for single-module installation in the available SO-DIMM slot.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 1x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2666 MHz |
| Maximum RAM | 8 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2666 (PC4-21328) |
| Bandwidth | 21.3 GB/s |
| Laptop Release date | 23 March 2020 |
Additional Notes
- The presence of a single SO-DIMM slot prevents the utilization of dual-channel memory architecture, restricting the system to single-channel bandwidth speeds.
- Onboard memory integrated into the motherboard of the HP ENVY 13-ba0007tx typically dictates the total capacity ceiling, meaning any module replacement must remain within the 8 GB BIOS addressable limit.
- Installation of higher frequency modules will result in an automatic downclock to 2666 MHz to match the hardcoded controller limitations.
- Physical access to the memory slot requires the removal of adhesive rubber strips and a specialized driver set to bypass the chassis bottom panel without causing structural damage.
- The 8 GB maximum threshold creates a significant bottleneck for memory-intensive background tasks and modern creative software suites that rely on substantial paging files.
- Internal heat management is critical during upgrades since the compact chassis lacks dedicated airflow for the memory module area during high-load operations.
