HP OMEN 15-dc0008no RAM upgrade specifications
The HP OMEN 15-dc0008no laptop features DDR4-SDRAM memory with 2x SO-DIMM slots for upgrade capacity. Compatible memory modules support frequencies of 2666 MHz. Maximum RAM upgrade capacity reaches 32 GB total, allowing users to expand the laptop's memory specifications from the factory configuration. SO-DIMM form factor memory modules are required for compatibility with this specific model. RAM upgrade slots accommodate standard laptop memory modules for performance enhancement.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2666 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2666 (PC4-21328) |
| Bandwidth | 21.3 GB/s |
| Laptop Release date | 21 June 2018 |
Additional Notes
- The HP OMEN 15-dc0008no accommodates 2 SO-DIMM slots, which restricts upgrade capacity to a maximum of 2 separate memory modules; this architecture does not permit stacking beyond the physical slot count.
- DDR4-2666 MHz represents a mid-tier speed tier. Modules rated for DDR4-3200 MHz or higher will downclock to 2666 MHz within this system, resulting in no performance gain from premium-speed modules and wasted expenditure on faster specifications.
- Reaching the 32 GB maximum requires 2x16 GB modules; single-module upgrades will leave one SO-DIMM slot vacant, preserving future upgrade flexibility but not achieving full system capacity on a single purchase.
- SO-DIMM form factor is standard for this chassis class. Laptop-specific memory is required; desktop DDR4 UDIMM modules are physically incompatible and cannot be inserted into these slots.
- The 2-slot configuration creates a potential bandwidth bottleneck if the system operates in single-channel mode (asymmetric module pairing). Matched pairs of identical capacity and speed preserve dual-channel operation and prevent memory throughput degradation.
- DDR4-2666 memory is mature and widely manufactured at competitive pricing; availability and cost per gigabyte remain favorable for this specification tier, supporting cost-effective upgrades to the 32 GB ceiling.
