LENOVO ThinkPad T460p RAM upgrade specifications

The Lenovo ThinkPad T460p laptop contains two SO-DIMM memory slots supporting DDR4-SDRAM upgrades. Maximum RAM capacity reaches 32 GB total, with compatible memory operating at 2133 MHz frequency specifications. Upgrade configurations allow users to expand existing memory modules within the two available slots to achieve maximum capacity specifications for this T-series model.

Additional Notes

• Dual channel memory architecture is only achievable when installing 2 modules of identical capacity and frequency.
• High frequency RAM modules with ratings above 2133 MHz will automatically downclock to match the system bus speed.
• The 32 GB threshold indicates compatibility with 16 GB high density non ECC modules per slot.
• The use of SO DIMM form factor requires 260 pin modules rather than the 204 pin standard used in previous DDR3 generations.
• Lack of soldered memory allows for total replacement of factory components without being limited by a fixed internal chip.
• Bandwidth limitations of the 2133 MHz clock speed will restrict the integrated GPU performance during memory intensive rendering tasks.
• Physical access to both slots typically requires removal of the entire base cover which involves releasing internal plastic clips after screw extraction.
• Mixing modules with different CAS latencies will force the system to operate at the timings of the slowest installed module.
• The chipset lacks support for 32 GB single stick modules making 16 GB the maximum individual capacity supported per interface.
