MSI Alpha 15 B5EEK-032XFR RAM upgrade specifications
MSI Alpha 15 B5EEK-032XFR laptop features 2x SO-DIMM slots supporting DDR4-SDRAM memory upgrades at 3200 MHz frequency. The system accommodates maximum RAM capacity of 64 GB total, with SO-DIMM form factor modules compatible for memory expansion. Specifications enable users to upgrade laptop memory to enhance multitasking performance and system responsiveness through compatible DDR4 memory modules installed in available SO-DIMM slots.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 17 February 2022 |
Additional Notes
- Dual channel mode requires identical module capacities across both slots to maximize memory controller bandwidth and eliminate single channel performance penalties.
- The MSI Alpha 15 B5EEK-032XFR motherboard architecture supports 32 GB modules in each socket to reach the peak addressable memory ceiling.
- Installation of memory clocked higher than 3200 MHz will result in automatic downclocking to the system bus limit due to chipset firmware restrictions.
- The SO-DIMM form factor necessitates physical hardware access through the bottom chassis panel which may involve piercing factory seal stickers in certain regional jurisdictions.
- Utilizing mismatched latency timings between two different RAM sticks forces the system to operate at the slowest common JEDEC profile to maintain stability.
- Upgrading to the maximum capacity provides the necessary overhead for virtual machine hosting and high resolution video rendering workflows that exceed standard gaming requirements.
- Integrated graphics performance scales directly with memory speed and configuration as the GPU shares the system pool rather than utilizing dedicated VRAM.
