MSI Alpha 17 A4DEK-010XIT RAM upgrade specifications
The MSI Alpha 17 A4DEK-010XIT laptop features DDR4-SDRAM memory upgrade specifications with two SO-DIMM slots supporting maximum capacity of 64 GB RAM. Compatible memory modules operate at 3200 MHz frequency and utilize SO-DIMM form factor. Upgrade configurations accommodate various capacity combinations within maximum specifications for enhanced system performance and multitasking capabilities.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 21 September 2020 |
Additional Notes
- Dual channel architecture requires matching module pairs to utilize the full available memory bandwidth for the Ryzen 4000 series processor in this MSI Alpha 17 A4DEK-010XIT.
- The absence of soldered memory on the motherboard allows for the total replacement of factory modules to reach the maximum 64 GB threshold.
- Physical installation is restricted to 260 pin small outline connectors which excludes standard desktop components or older DDR3 hardware.
- Installing modules with higher frequencies than 3200 MHz will result in automatic downclocking to the system bus limit determined by the chipset.
- Achieving the peak 64 GB capacity necessitates the use of high density 32 GB modules in each of the two available slots.
- Mixing modules with different CAS latencies will force the system to operate at the timings of the slowest installed stick.
- Accessing the internal SO-DIMM slots requires the removal of the entire lower chassis cover which may involve piercing a factory seal sticker in certain regions.
