MSI Gaming GE62 6QF Apache Pro 001-HID2 RAM upgrade specifications

MSI GE62 6QF Apache Pro 001-HID2 MSI GE62 6QF Apache Pro 001-HID2 MSI GE62 6QF Apache Pro 001-HID2 MSI GE62 6QF Apache Pro 001-HID2 MSI GE62 6QF Apache Pro 001-HID2

MSI GE62 6QF Apache Pro 001-HID2 gaming laptop supports DDR4-SDRAM memory upgrades through 2x SO-DIMM slots. Maximum RAM capacity reaches 32 GB total. Compatible memory modules operate at 2133 MHz frequency and utilize SO-DIMM form factor. Specifications enable users to upgrade from factory-installed memory to higher capacity configurations within the 32 GB maximum supported limit.

Memory Upgrade Specifications

SpecificationValue
Memory slots2x SO-DIMM
Form factorSO-DIMM
Memory typeDDR4-SDRAM
Frequency2133 MHz
Maximum RAM32 GB
Voltage1.2V
Number of pins260-pin
InterfacePC4
PC Speed RatingPC4-2133 (PC4-17064)
Bandwidth17.1 GB/s
Laptop Release date15 February 2018

Additional Notes

  • The dual channel configuration requirement necessitates installing modules in identical pairs to achieve maximum memory bandwidth for the MSI GE62 6QF Apache Pro 001-HID2.
  • Internal access to the 2 SO-DIMM slots requires the removal of the entire base panel which involves penetrating a factory seal sticker.
  • Installation of memory modules with frequencies higher than 2133 MHz results in automatic downclocking to match the hardcoded chipset limitations.
  • The 32 GB maximum capacity occupies all available slots and prevents further expansion without replacing existing hardware.
  • Standard voltage DDR4 modules are required as the motherboard lacks support for legacy low voltage or high voltage overclocking profiles.
  • Physical height constraints within the chassis limit compatibility to standard height SO-DIMM modules and exclude those equipped with tall integrated heat spreaders.
  • Upgrading memory requires the use of non-conductive prying tools to avoid short-circuiting sensitive surface-mounted components near the retention clips.
