MSI Gaming GL65 Leopard 10SER-026FR RAM upgrade specifications
MSI GL65 Leopard 10SER-026FR gaming laptop memory upgrade specifications indicate DDR4-SDRAM compatibility with two SO-DIMM slots available for RAM expansion. Maximum supported capacity reaches 64 GB total memory. Compatible memory modules operate at 2666 MHz frequency. Upgrade slots accommodate standard SO-DIMM form factor modules. Specifications support memory expansion for enhanced multitasking and performance in the GL series gaming platform.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2666 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2666 (PC4-21328) |
| Bandwidth | 21.3 GB/s |
| Laptop Release date | 10 April 2020 |
Additional Notes
- The dual channel architecture requires symmetrical module pairs to achieve maximum memory bandwidth and prevent single channel throughput bottlenecks.
- Upgrading the MSI GL65 Leopard 10SER-026FR to the maximum capacity necessitates the removal of all existing pre installed modules due to the two slot physical limitation.
- Installing modules with frequencies higher than 2666 MHz will result in automatic downclocking to match the system bus speed constraints.
- Accessing the SO DIMM slots requires the removal of the entire bottom chassis panel which may involve piercing a factory seal sticker in certain regions.
- The use of high density 32 GB modules is necessary to reach the 64 GB limit because of the restricted number of available slots.
- Non ECC unbuffered modules are required for compatibility as the chipset does not support error correcting code memory.
- Mixing modules with different CAS latencies will force the system to operate at the timings of the slowest installed stick.
