MSI Gaming GP62MVR 7RFX-1227XES Leopard Pro RAM upgrade specifications
MSI GP62MVR 7RFX-1227XES Leopard Pro gaming laptop specifications indicate memory upgrade capacity with 2x SO-DIMM slots supporting DDR4-SDRAM modules. Compatible RAM upgrades accommodate maximum capacity of 32 GB total, operating at 2400 MHz frequency. SO-DIMM form factor represents the standard memory configuration for this MSI Gaming GP series model, allowing users to expand from factory-installed specifications to maximum supported capacity.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2400 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2400 (PC4-19200) |
| Bandwidth | 19.2 GB/s |
| Laptop Release date | 12 February 2018 |
Additional Notes
- The 32 GB ceiling requires both slots to accommodate 16 GB modules, which may necessitate discarding existing memory rather than adding to it.
- DDR4-2400 represents the certified speed threshold, though modules rated at higher frequencies will downclock to maintain system stability.
- SO-DIMM architecture indicates the MSI GP62MVR 7RFX-1227XES Leopard Pro uses laptop-specific memory modules incompatible with desktop DIMM standards despite identical generation technology.
- Dual-channel configuration becomes accessible only when matched module capacities populate both slots, directly affecting memory bandwidth availability.
- Seventh-generation Intel mobile platforms typically restrict JEDEC support to DDR4-2400, making faster XMP profiles ineffective without BIOS-level overclocking.
- Operating a single module leaves half the potential memory bandwidth unused, potentially creating performance constraints in bandwidth-intensive applications.
- Non-matching module timings or voltage specifications between slots may force the memory controller to adopt the most conservative parameters across both channels.
- The SO-DIMM form factor requires bottom panel removal for installation access, potentially affecting warranty status if tamper-evident seals are present.
- Mixing different memory ranks (single-rank and dual-rank modules) can introduce compatibility issues or force single-channel operation on affected slots.
- Heat dissipation in the confined laptop chassis may limit sustained performance when operating at maximum capacity under thermal stress conditions.
