MSI Modern 14 A10M-446XIT RAM upgrade specifications
The MSI Modern 14 A10M-446XIT laptop features one SO-DIMM slot for memory upgrade. Compatible RAM specifications include DDR4-SDRAM memory operating at 2666 MHz frequency. Maximum supported capacity reaches 32 GB total RAM. Upgrade options allow expansion of the existing memory configuration through the single available slot. The laptop supports standard SO-DIMM form factor modules for memory expansion and enhancement of system performance specifications.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 1x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2666 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2666 (PC4-21328) |
| Bandwidth | 21.3 GB/s |
| Laptop Release date | 13 December 2019 |
Additional Notes
- The single slot configuration in the MSI Modern 14 A10M-446XIT precludes dual channel memory operation, limiting the bandwidth available to the integrated graphics processor.
- Upgrading memory requires the total replacement of the existing module because no secondary expansion slot is available for adding capacity.
- The motherboard architectural limit restricts memory density to 32 GB per module, which represents the ceiling for multitasking performance.
- Installing memory with frequencies exceeding 2666 MHz results in automatic downclocking to match the native system bus speed.
- The SO-DIMM form factor necessitates the use of 260 pin modules specifically designed for mobile chipsets.
- Thermal constraints within the compact chassis favor the use of 1.2V low voltage modules to minimize heat generation during high load cycles.
- Accessing the internal memory slot requires the removal of the bottom base cover, which may involve penetrating factory seals that impact regional warranty terms.
