MSI Modern 14 A10M-682CA RAM upgrade specifications
MSI Modern 14 A10M-682CA laptop RAM upgrade specifications include one SO-DIMM slot supporting DDR4-SDRAM memory. Maximum memory capacity reaches 32 GB total. Compatible RAM operates at 2666 MHz frequency. Upgrade specifications accommodate SO-DIMM form factor modules. Memory configuration enables expansion from factory baseline to maximum supported capacity of 32 GB.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 1x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2666 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2666 (PC4-21328) |
| Bandwidth | 21.3 GB/s |
| Laptop Release date | 23 December 2019 |
Additional Notes
- The single slot configuration on the MSI Modern 14 A10M-682CA necessitates a full module replacement rather than an addition for memory expansions.
- The absence of dual channel memory architecture restricts the maximum possible bandwidth and impacts integrated graphics performance during memory intensive tasks.
- Utilizing a module with a frequency higher than 2666 MHz results in an automatic downclocking to match the hardware controller limit.
- High density 32 GB sticks require a 1.2V SO-DIMM profile to ensure power delivery stability within the thin chassis thermal envelope.
- Memory latency remains fixed at single channel speeds which can create a processing bottleneck for specific multi threaded applications.
- Physical access to the memory slot typically involves removing the entire bottom panel which may involve piercing a factory seal sticker in certain regions.
