MSI Prestige 15 A10SC-002IT RAM upgrade specifications

MSI 15 A10SC-002IT MSI 15 A10SC-002IT MSI 15 A10SC-002IT MSI 15 A10SC-002IT MSI 15 A10SC-002IT

MSI Prestige 15 A10SC-002IT laptop supports DDR4-SDRAM memory upgrades through 2x SO-DIMM slots. Maximum RAM capacity reaches 64 GB total. Compatible memory modules operate at 2666 MHz frequency. Upgrade specifications indicate SO-DIMM form factor for memory expansion. Current configuration supports DDR4 technology with dual-slot configuration enabling memory capacity expansion up to maximum specifications.

Memory Upgrade Specifications

SpecificationValue
Memory slots2x SO-DIMM
Form factorSO-DIMM
Memory typeDDR4-SDRAM
Frequency2666 MHz
Maximum RAM64 GB
Voltage1.2V
Number of pins260-pin
InterfacePC4
PC Speed RatingPC4-2666 (PC4-21328)
Bandwidth21.3 GB/s
Laptop Release date17 October 2019

Additional Notes

  • Dual channel memory architecture requires installing modules in pairs to maximize the integrated memory controller throughput.
  • The MSI Prestige 15 A10SC-002IT utilizes a volatile memory standard that prevents the use of newer DDR5 modules due to physical pin alignment and voltage differences.
  • Installing 32 GB modules in both available slots is necessary to reach the documented upper ceiling of system stability.
  • Latencies will revert to the slowest installed module if mismatched timing profiles are used across the 2 SO-DIMM interfaces.
  • Higher frequency RAM kits will automatically downclock to 2666 MHz to maintain synchronization with the processor bus limitations.
  • Internal component access for memory replacement necessitates the removal of the bottom chassis panel which may involve piercing factory seal stickers.
  • The absence of soldered memory on the motherboard ensures that both banks remain field replaceable for long-term hardware maintenance.
