MSI Prestige PS42 8RC-029ES RAM upgrade specifications

MSI PS42 8RC-029ES MSI PS42 8RC-029ES MSI PS42 8RC-029ES MSI PS42 8RC-029ES MSI PS42 8RC-029ES

MSI Prestige PS42 8RC-029ES RAM upgrade specifications indicate single SO-DIMM slot compatibility with DDR4-SDRAM memory operating at 2400 MHz frequency. Maximum supported capacity reaches 16 GB, enabling users to expand the laptop's memory through compatible upgrades. The SO-DIMM form factor confirms standard mobile memory module compatibility for this Prestige series model. DDR4 specifications ensure modern memory performance standards for enhanced multitasking and application responsiveness on the PS42 8RC-029ES platform.

Memory Upgrade Specifications

SpecificationValue
Memory slots1x SO-DIMM
Form factorSO-DIMM
Memory typeDDR4-SDRAM
Frequency2400 MHz
Maximum RAM16 GB
Voltage1.2V
Number of pins260-pin
InterfacePC4
PC Speed RatingPC4-2400 (PC4-19200)
Bandwidth19.2 GB/s
Laptop Release date12 November 2018

Additional Notes

  • Single-channel memory architecture limits theoretical bandwidth to approximately 19 GB/s compared to 38 GB/s available in dual-channel configurations.
  • Integrated graphics performance may experience significant reductions due to single-channel memory operation, particularly in GPU-intensive applications.
  • Soldered RAM occupies the second memory channel, preventing dual-channel operation regardless of SO-DIMM installation.
  • Memory replacement requires removal of the existing SO-DIMM module rather than addition alongside existing capacity.
  • DDR4-2400 specification indicates 8th generation Intel Core processor compatibility with locked memory controller speeds.
  • Installing DDR4 modules rated above 2400 MHz will result in automatic downclocking to 2400 MHz regardless of module specifications.
  • 16 GB ceiling requires single-rank or dual-rank 16 GB SO-DIMM module, as 2 module slots are not available for capacity distribution.
  • Memory access latency remains constant across all capacity configurations due to fixed 2400 MHz frequency ceiling.
  • System disassembly to access the SO-DIMM slot may void warranty depending on regional service policies and seal placements.
  • Non-standard voltage modules (low-voltage or overclocking variants) may cause POST failures or system instability due to firmware compatibility restrictions.
  • SO-DIMM 260-pin physical standard is required; desktop DIMM modules are mechanically incompatible regardless of electrical specifications.
  • ECC SO-DIMM modules will not function as the consumer-grade chipset lacks error-correction support.
