MSI Workstation WS65 9TJ-006 RAM upgrade specifications

The MSI WS65 9TJ-006 workstation features DDR4-SDRAM memory upgrade specifications with 2x SO-DIMM slots supporting a maximum RAM capacity of 64 GB. Compatible memory modules operate at 2666 MHz frequency with SO-DIMM form factor. The specifications enable memory expansion from base configurations to the supported maximum capacity of 64 GB, allowing users to upgrade memory capacity as required for workstation performance demands.

Additional Notes

• The dual channel memory architecture requires installing modules in pairs to achieve maximum memory bandwidth for complex rendering and workstation tasks.
• Upgrading the MSI WS65 9TJ-006 involves navigating a flipped motherboard design which necessitates the removal of the heat pipe assembly and entire PCB to access the SODIMM slots located on the underside of the board.
• Installing modules with frequencies higher than 2666 MHz results in automatic downclocking to the system bus limit imposed by the 9th Generation Intel chipset.
• The 64 GB maximum capacity is achieved by utilizing 32 GB high density modules which may require a BIOS update to ensure proper recognition and stability.
• Memory modules lacking an onboard thermal spreader are preferred due to the extremely tight physical clearance between the motherboard and the bottom chassis plate.
• Mixing modules with different CAS latencies forces the system to default to the timings of the slowest stick which increases overall memory latency.
• Total system power draw increases slightly when transitioning from single to dual rank 32 GB modules affecting battery runtime during mobile professional workflows.
