ACER TravelMate TMP215-52-30WG RAM upgrade specifications
Acer TravelMate P2 Series TMP215-52-30WG laptop RAM upgrade specifications indicate DDR4-SDRAM memory compatibility. The device features 2x SO-DIMM slots supporting maximum RAM capacity of 32 GB. Memory operates at 2133 MHz frequency. Compatible upgrades utilize SO-DIMM form factor. Current specifications enable memory expansion up to maximum supported capacity through available upgrade slots.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2133 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2133 (PC4-17064) |
| Bandwidth | 17.1 GB/s |
| Laptop Release date | 04 February 2021 |
Additional Notes
- The dual-channel architecture requires 2 identical modules to achieve peak memory bandwidth and prevent single-channel latency bottlenecks.
- Installing modules with higher frequency ratings will result in an automatic downclock to 2133 MHz due to chipset synchronization limits.
- The ACER TravelMate TMP215-52-30WG necessitates 260-pin SO-DIMM hardware which is incompatible with older DDR3 or desktop-class DIMM slots.
- Total addressable memory is capped at 32 GB regardless of operating system capabilities or virtual memory settings.
- Maintenance of the internal memory slots requires removal of the base plate which typically involves penetrating factory seals depending on local regional warranty terms.
- The absence of soldered memory on the motherboard indicates that both slots are fully serviceable for symmetrical capacity upgrades.
- Using 16 GB modules in both slots is the only method to reach the maximum supported hardware threshold.
