ASUS ProArt StudioBook W730G2T-H8007R RAM upgrade specifications
ASUS ProArt StudioBook Pro X W730G2T-H8007R RAM upgrade specifications include four SO-DIMM memory slots supporting DDR4-SDRAM at 2666 MHz frequency. Maximum supported capacity reaches 128 GB total memory. Compatible upgrades utilize DDR4 SO-DIMM form factor modules. Specifications enable expansion from baseline configuration through addition of compatible DDR4-SDRAM modules to achieve maximum RAM capacity across available upgrade slots.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 4x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2666 MHz |
| Maximum RAM | 128 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2666 (PC4-21328) |
| Bandwidth | 21.3 GB/s |
| Laptop Release date | 27 January 2020 |
Additional Notes
- The presence of 4 physical SO-DIMM slots implies a dual-channel architecture where memory modules must be installed in matched pairs to maintain peak data throughput.
- High density 32 GB modules are required in every available slot to reach the 128 GB ceiling supported by the ASUS ProArt StudioBook W730G2T-H8007R internal controller.
- Integrating faster memory modules results in automatic downclocking to 2666 MHz due to firmware limitations on the system bus.
- Populating all 4 slots increases the thermal load within the chassis and may lead to slight increases in power consumption from the battery.
- Total memory capacity at the 128 GB limit allows for handling large scale 3D rendering and 8K video timelines without triggering virtual memory swapping to the storage drive.
- Physical access to the secondary memory bank often requires removing the keyboard or secondary internal shielding depending on the motherboard layout.
- Mixing modules with different CAS latencies forces the system to operate at the timings of the slowest installed chip.
