ASUS ROG G512LU-AL056 RAM upgrade specifications
The ASUS ROG Strix G15 G512LU-AL056 features two SO-DIMM memory slots supporting DDR4-SDRAM upgrade capabilities. The laptop accommodates a maximum RAM capacity of 32 GB, with compatible memory operating at 3200 MHz frequency. Upgrade specifications indicate SO-DIMM form factor modules are required for memory expansion on this gaming model. The dual-slot configuration enables users to install matching DDR4 memory modules to enhance system performance and multitasking capabilities.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 04 February 2021 |
Additional Notes
- Dual channel architecture requires matching memory modules to reach peak data transfer rates and minimize latency during high demand processing on the ASUS ROG G512LU-AL056.
- The absence of soldered memory on the motherboard ensures that the total system capacity is replaceable if a hardware failure occurs in the primary slot.
- Operating modules at 3200 MHz requires the processor to support this clock speed or the system will downclock the memory to the nearest compatible frequency.
- Total memory expansion is restricted by the density of available 16 GB SO-DIMM modules within a 2 slot configuration.
- Lower voltage DDR4 modules improve thermal performance and extend battery life compared to older memory standards.
- Installation of unauthorized memory capacities beyond 32 GB may result in system instability or failure to pass the power on self test.
- Physical access to the dual SO-DIMM slots typically necessitates the removal of the bottom chassis panel and the disconnection of the internal battery to prevent short circuits.
