ASUS ROG G513QE-HF105T RAM upgrade specifications
ASUS ROG Strix G15 model G513QE-HF105T features DDR4-SDRAM memory upgrade specifications with 2x SO-DIMM slots supporting maximum RAM capacity of 32 GB. Compatible memory modules operate at 3200 MHz frequency using SO-DIMM form factor. Upgrade specifications enable expansion from factory-installed configuration to maximum 32 GB total capacity through replacement or addition of compatible DDR4 memory modules in available slots.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 16 January 2022 |
Additional Notes
- The ASUS ROG G513QE-HF105T supports DDR4-3200 memory exclusively, which constrains upgrade purchases to modules certified for this specific standard. Any attempt to install faster DDR4 variants (3600 MHz or above) will operate at reduced 3200 MHz speeds, negating performance gains and creating inefficient purchasing decisions.
- With 2 SO-DIMM slots and a 32 GB maximum capacity, the upgrade path requires complete slot occupation. Installing a single high-capacity module leaves the second slot unfilled and prevents symmetric dual-channel operation, resulting in measurable performance loss during memory-intensive tasks compared to matched-pair configurations.
- SO-DIMM form factor compatibility is non-negotiable on this mobile workstation. Standard UDIMM desktop memory is physically incompatible and will not fit within the laptop's internal spacing, making in-store purchases risky without pre-verified SO-DIMM specifications.
- Memory bandwidth saturation may occur if both DDR4-3200 SO-DIMMs are populated at maximum capacity (32 GB total). The dual-channel architecture will sustain approximately 51.2 GB/s throughput, which can become a limiting factor during simultaneous high-bandwidth operations like video rendering or large dataset transfers on this gaming-class platform.
- Warranty considerations require purchasing memory from component manufacturers with JEDEC DDR4 compliance certifications. Non-certified third-party modules may trigger warranty exclusions if memory-related hardware failures occur, even though the installation itself remains user-serviceable on this model.
