ASUS ROG G513QM-ES74 RAM upgrade specifications
ASUS ROG Strix G15 G513QM-ES74 laptop memory upgrade specifications include two SO-DIMM slots supporting DDR4-SDRAM memory at 3200 MHz frequency. The upgrade capacity reaches a maximum of 32 GB total RAM. Compatible memory modules must match SO-DIMM form factor specifications for proper installation in available slots. The G513QM-ES74 supports standard DDR4 memory configurations with specifications meeting laptop memory standards for gaming and performance applications.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 04 January 2021 |
Additional Notes
- The dual-channel architecture requires matching module pairs to maximize memory bandwidth for the Ryzen processor in this ASUS ROG G513QM-ES74.
- The usage of SO-DIMM slots implies that the factory memory is not soldered to the motherboard, allowing for complete replacement of both modules.
- The system operates on an unbuffered non-ECC signal type, making server-grade registered memory incompatible with the motherboard logic.
- Installations exceeding the 32 GB threshold will likely result in a failure to post or forced downclocking of the memory controller.
- Achieving the 3200 MHz frequency requires modules with a compatible JEDEC profile to ensure the BIOS recognizes the speed without manual voltage adjustments.
- The physical height constraints of the chassis limit upgrades to standard height SO-DIMM modules, excluding those with tall integrated heat spreaders.
- Replacing existing modules serves as the only path for expansion since no vacant slots exist for adding supplemental capacity.
