ASUS ROG G513QM-HN042T RAM upgrade specifications
ASUS ROG Strix G15 G513QM-HN042T supports DDR4-SDRAM memory upgrades with 2x SO-DIMM slots and maximum capacity of 32 GB. The compatible memory specifications include 3200 MHz frequency modules. RAM upgrade configurations allow installation of matched or single modules up to the maximum supported capacity. Replacement memory must comply with SO-DIMM form factor specifications and DDR4 standards for compatibility with this gaming laptop model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 10 December 2020 |
Additional Notes
- The dual-channel architecture requires installing matched pairs of memory modules to optimize the memory controller bandwidth within the ASUS ROG G513QM-HN042T chassis.
- Upgrading to the maximum 32 GB threshold necessitates the replacement of both factory modules since the system lacks additional vacant slots.
- The motherboard firmware limits operational frequency to 3200 MHz, meaning modules with higher rated speeds will automatically downclock to maintain stability.
- Utilizing high-density 16 GB SO-DIMM sticks allows for the highest possible multitasking overhead before triggering virtual memory swapping on the primary drive.
- The absence of soldered memory on this specific platform ensures that the entire system memory remains serviceable and replaceable in the event of hardware failure.
- Optimal latency performance is achieved by selecting modules with matching CL timings to prevent the BIOS from defaulting to the slowest common denominator.
- Integrated graphics components share the system memory pool, so increasing total capacity directly expands the available video buffer for rendering tasks.
