ASUS ROG G513QM-HN027T-BE RAM upgrade specifications
The ASUS ROG Strix G15 G513QM-HN027T-BE laptop features two SO-DIMM memory slots supporting DDR4-SDRAM upgrade specifications. Maximum RAM capacity reaches 32 GB with compatible modules operating at 3200 MHz frequency. The device accommodates SO-DIMM form factor memory modules, enabling users to upgrade existing RAM configurations within the specified capacity and compatibility parameters.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 19 December 2020 |
Additional Notes
- The dual slot configuration requires the removal of existing modules to reach the maximum capacity as no memory is soldered to the mainboard.
- Operating the ASUS ROG G513QM-HN027T-BE with two identical modules enables dual channel bandwidth which is necessary to prevent integrated bottlenecking during high refresh rate gaming.
- The system uses 260 pin physical interfaces restricted to 1.2V power delivery which precludes the use of high voltage overclocked kits without manual XMP profile support in the BIOS.
- Standard JEDEC profiles are required for the memory to hit the rated 3200 MHz speed automatically because the chipset lacks consumer adjustable timing controls.
- The 32 GB ceiling indicates a firmware limitation or a density restriction per slot that prevents the utilization of 32 GB single sticks.
- Installing modules with higher rated frequencies will result in a downclock to the maximum supported system bus speed of 3200 MHz.
- Internal access for hardware swaps involves removing the bottom chassis panel which may expose sensitive internal ribbons for the integrated light bar.
