ASUS ROG G513RW-ES94 RAM upgrade specifications
ASUS ROG Strix G15 G513RW-ES94 laptop supports DDR5-SDRAM memory upgrade through two SO-DIMM slots. Maximum RAM capacity reaches 32 GB total, with compatible modules operating at 4800 MHz frequency. Specifications indicate SO-DIMM form factor memory modules are required for upgrade compatibility. Existing memory configuration allows expansion to specifications supporting high-performance gaming and workstation applications.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
| Laptop Release date | 20 January 2022 |
Additional Notes
- The ASUS ROG G513RW-ES94 system architecture limits total capacity to 32 GB despite DDR5 technology typically supporting higher densities, indicating motherboard chipset restrictions rather than memory standard limitations.
- DDR5-4800 operates at JEDEC baseline specification, meaning memory modules rated at higher frequencies will downclock to 4800 MHz when installed, negating any performance premium paid for faster RAM.
- SO-DIMM slots require physical access through bottom panel removal, which may involve breaking tamper-evident warranty seals depending on regional service policies.
- Dual-channel configuration requires matched pairs for optimal bandwidth utilization, meaning asymmetric capacity installations will force single-channel operation on the excess capacity portion.
- DDR5 SO-DIMM modules operate at 1.1V standard voltage with no voltage adjustment available in mobile platforms, eliminating manual overclocking potential regardless of module specifications.
- The 32 GB ceiling constrains workloads like large dataset processing or virtual machine allocation compared to desktop DDR5 platforms supporting 128 GB or higher in equivalent price ranges.
- Mixed-density configurations pairing 8 GB and 16 GB modules will function but sacrifice performance consistency due to rank asymmetry affecting memory interleaving patterns.
- Non-ECC unbuffered memory requirement means modules with error correction or registered specifications will either fail POST or operate with features disabled.
- Temperature management depends on module height clearance beneath the keyboard assembly, with taller heat spreader designs potentially causing fitment interference in this chassis generation.
- DDR5 on-die ECC operates transparently at hardware level but does not provide system-level error reporting, differentiating it from true ECC implementations in workstation platforms.
