ASUS ROG G713QY-K4005T RAM upgrade specifications
The ASUS ROG Strix G17 series model G713QY-K4005T features DDR4-SDRAM memory upgrade specifications with 2x SO-DIMM slots. The laptop supports a maximum RAM capacity of 32 GB total memory. Compatible upgrades utilize SO-DIMM form factor modules operating at 3200 MHz frequency. Specifications indicate the upgrade slots accommodate DDR4 memory technology for enhanced system performance and multitasking capabilities.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 04 June 2021 |
Additional Notes
- Dual channel architecture requires matching memory modules to reach peak data transfer rates and prevent bandwidth throttling.
- The 32 GB ceiling indicates a localized motherboard limitation or firmware restriction regardless of available high capacity SO-DIMM modules on the market.
- Utilizing memory with lower latency timings than stock components can improve frame time consistency during heavy computational loads.
- The ASUS ROG G713QY-K4005T internal layout necessitates the simultaneous replacement of both pre-installed modules to achieve the maximum supported memory footprint.
- Physical installation depends on standard small outline interface pins which do not support desktop sized hardware or older DDR3 generations.
- Voltage compatibility must remains at 1.2V to ensure system stability and prevent overheating within the compact chassis.
- Installing modules with frequencies exceeding 3200 MHz will result in automatic downclocking to the maximum hardware rated speed.
