ASUS ROG G815LR-S9002W RAM upgrade specifications

ASUS G815LR-S9002W ASUS G815LR-S9002W ASUS G815LR-S9002W ASUS G815LR-S9002W ASUS G815LR-S9002W

The ASUS ROG Strix G18 G815LR-S9002W supports DDR5-SDRAM memory upgrades with 2x SO-DIMM slots capable of accommodating a maximum of 64 GB total capacity. The compatible memory operates at 5600 MHz frequency. Upgrade specifications indicate SO-DIMM form factor modules are required for this gaming laptop model. The memory configuration allows for flexible RAM expansion to meet performance requirements for intensive computing tasks.

Memory Upgrade Specifications

SpecificationValue
Memory slots2x SO-DIMM
Form factorSO-DIMM
Memory typeDDR5-SDRAM
Frequency5600 MHz
Maximum RAM64 GB
Voltage1.1V
Number of pins262-pin
InterfacePC5
PC Speed RatingPC5-5600 (PC5-44800)
Bandwidth44.8 GB/s

Additional Notes

  • Dual slot architecture facilitates symmetrical memory channel operation for improved data throughput in bandwidth intensive applications.
  • The ASUS ROG G815LR-S9002W utilizes high frequency modules requiring integrated power management circuits on the memory board for voltage regulation.
  • Internal space limitations necessitate a compact form factor that excludes the use of tall heat spreaders or desktop class hardware.
  • Achieving maximum capacity requires the installation of 32 GB modules in both available locations to ensure hardware stability.
  • Lower latency timing profiles remain dependent on firmware compatibility and may revert to standard specifications if mismatched hardware is introduced.
  • Physical access to the motherboard for maintenance requires the removal of the lower chassis assembly and potential disconnection of internal battery connectors.
  • Signal integrity for high speed transfers depends on the use of non buffered non ECC components within the physical interface.
