ASUS ROG G533ZW-LN017W RAM upgrade specifications
ASUS ROG Strix SCAR 15 G533ZW-LN017W laptop accommodates DDR5-SDRAM memory upgrades through two SO-DIMM slots. Maximum supported RAM capacity reaches 64 GB total, with compatible modules operating at 4800 MHz frequency. Memory upgrade specifications enable system enhancement for improved multitasking and performance optimization on gaming and professional applications.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
| Laptop Release date | 04 March 2022 |
Additional Notes
- Dual channel mode requires identical module capacities in both slots to ensure peak memory bandwidth for the ASUS ROG G533ZW-LN017W processor.
- Upgrading beyond the factory configuration requires 262 pin modules specifically designed for the lower voltage requirements of the DDR5 standard.
- The absence of soldered memory on the motherboard allows for the total replacement of original modules to reach the 64 GB threshold.
- Latency performance depends on the integrated memory controller capacity to maintain 4800 MHz speeds when both slots are occupied by high density modules.
- Physical installation requires grounded handling to protect the sensitive traces of the high frequency SO DIMM interface from electrostatic discharge.
- Mixing modules with different timings will force the system to default to the slowest common latency profile to maintain stability.
- Thermal dissipation within the chassis is affected by the height of aftermarket memory heat spreaders which must remain within standard SO DIMM vertical clearances.
