ASUS ROG G635LR-RW011W RAM upgrade specifications

ASUS G635LR-RW011W ASUS G635LR-RW011W ASUS G635LR-RW011W ASUS G635LR-RW011W

ASUS ROG Strix SCAR 16 model G635LR-RW011W features DDR5-SDRAM memory upgrade specifications with two SO-DIMM slots supporting maximum capacity of 64 GB total RAM. Compatible memory operates at 5600 MHz frequency. Upgrade slots accommodate SO-DIMM form factor modules, enabling expansion from factory configuration to maximum specifications of 64 GB DDR5 memory capacity for enhanced system performance and multitasking capabilities.

Memory Upgrade Specifications

SpecificationValue
Memory slots2x SO-DIMM
Form factorSO-DIMM
Memory typeDDR5-SDRAM
Frequency5600 MHz
Maximum RAM64 GB
Voltage1.1V
Number of pins262-pin
InterfacePC5
PC Speed RatingPC5-5600 (PC5-44800)
Bandwidth44.8 GB/s

Additional Notes

  • The DDR5-SDRAM requirement in the ASUS ROG G635LR-RW011W prevents backward compatibility with DDR4 modules due to different voltage standards and physical notch positioning.
  • The 64 GB maximum capacity suggests a chipset limitation that will prevent recognition of higher-density modules even if physically installed.
  • The 5600 MHz frequency represents the JEDEC standard speed, though the system may accept higher-rated modules that will downclock to this baseline.
  • SO-DIMM form factor restricts upgrade options to laptop-specific modules, which typically carry a price premium over desktop DIMM equivalents.
  • Mixing modules with different speeds will force all installed memory to operate at the slowest module's frequency.
  • The dual-slot configuration limits expansion to either replacing existing modules entirely or adding a second module to match the first.
  • Mismatched memory capacities between slots will disable dual-channel mode, effectively halving memory bandwidth.
  • Non-matching CAS latency timings between modules may cause system instability or force conservative timing profiles.
  • DDR5's on-die ECC feature operates independently of system-level ECC support and remains transparent to most users.
  • Voltage deviations from the DDR5 standard 1.1V specification may void manufacturer warranties or trigger thermal throttling.
  • The absence of Registered or Load-Reduced DIMM support means only unbuffered SO-DIMMs will function correctly.
  • Installing modules while residual charge remains in the system may corrupt the DDR5 Power Management IC.
