ASUS ROG G733ZW-LL006W RAM upgrade specifications
ASUS ROG Strix SCAR 17 model G733ZW-LL006W supports DDR5-SDRAM memory upgrades. The laptop features two SO-DIMM slots for RAM installation, with a maximum capacity of 64 GB. Compatible memory operates at 4800 MHz frequency. Specifications indicate support for DDR5 technology in SO-DIMM form factor, enabling users to upgrade memory configurations for enhanced system performance and multitasking capabilities.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
| Laptop Release date | 10 January 2022 |
Additional Notes
- The ASUS ROG G733ZW-LL006W supports DDR5-SDRAM exclusively, which means DDR4 modules cannot be installed regardless of physical compatibility attempts, as the memory controller and motherboard signaling are incompatible at the protocol level.
- Two SO-DIMM slots create a 32 GB per-slot ceiling for maximum capacity configurations. Uneven module populations (such as 16 GB plus 32 GB) will operate in single-channel mode on the unpopulated slot, reducing memory bandwidth by approximately 50 percent compared to dual-channel operation.
- The 4800 MHz specification represents the JEDEC standard for DDR5, though many DDR5 modules ship with XMP/EXPO profiles rated higher. Non-standard frequencies above 4800 MHz may require BIOS stability tuning and can void certain warranty provisions if system instability results.
- SO-DIMM modules occupy a smaller physical footprint than standard DIMM form factors, which limits availability in the aftermarket. Module selection often requires filtering by the SO-DIMM specification rather than searching general DDR5 stock.
- Upgrading from the factory configuration to the 64 GB maximum requires sourcing 2x 32 GB SO-DIMM modules, as single 48 GB or 56 GB configurations are unavailable in this form factor. This creates a discontinuous upgrade path where users transition directly from lower capacities to the full 64 GB tier.
- Memory installation in this platform typically requires removal of the keyboard deck or base panel. Warranty coverage remains intact only if the upgrade is performed by authorized service centers or if the manufacturer explicitly authorizes user-level memory installation in documentation.
