ASUS ROG G733ZW-LL093W-BE RAM upgrade specifications
ASUS ROG Strix SCAR 17 model G733ZW-LL093W-BE features DDR5-SDRAM memory upgrade specifications. The laptop contains 2x SO-DIMM slots supporting maximum RAM capacity of 64 GB. Compatible memory operates at 4800 MHz frequency with SO-DIMM form factor. Upgrade options allow installation of DDR5 modules to enhance system performance and multitasking capabilities on this gaming-focused platform.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
| Laptop Release date | 10 January 2022 |
Additional Notes
- The dual slot configuration allows for a symmetrical dual channel architecture which doubles the potential memory bandwidth compared to single channel setups.
- The DDR5 standard utilized by the ASUS ROG G733ZW-LL093W-BE features On-Die Error Correction Code to improve system stability during high load scenarios without requiring specialized server hardware.
- Upgrading beyond the 64 GB threshold is blocked by the internal memory controller limitations despite the existence of higher capacity modules on the market.
- Both factory modules must be removed to reach the maximum capacity as no memory is permanently soldered to the main logic board.
- Lower latency modules are compatible provided they operate at the standard 1.1 volt specification to avoid power delivery instability.
- The use of SO-DIMM modules requires manual physical seating into the tension clips but avoids the permanent hardware lock-in associated with LPDDR5 designs.
- Installing modules with speeds exceeding 4800 MHz will result in a down-clocking to the platform ceiling, providing no functional performance advantage.
