ASUS ROG G712LW-EV024T RAM upgrade specifications
ASUS ROG Strix G712LW-EV024T laptop supports DDR4-SDRAM memory upgrade through dual SO-DIMM slots. Maximum compatible RAM capacity reaches 32 GB total. Specifications indicate support for 3200 MHz frequency modules. The G712LW-EV024T accommodates SO-DIMM form factor memory modules for upgrade purposes. Compatible DDR4 modules can be installed in both available slots to achieve maximum memory configuration.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 05 February 2020 |
Additional Notes
- The dual slot configuration requires the removal of existing modules to reach the maximum capacity if the device currently occupies both physical interfaces.
- Operating the ASUS G712LW-EV024T with mismatched module capacities leads to asynchronous dual channel mode which reduces memory bandwidth for heavy multitasking.
- The specific frequency indicated for this system necessitates hardware with a Low Voltage 1.2V profile to maintain stability and prevent thermal throttling within the compact chassis.
- Legacy DDR3 or high voltage desktop memory modules are physically incompatible due to the notch placement on the SO-DIMM circuit board.
- Internal access for memory replacement entails removing the bottom panel which involves fragile ribbon cables for the integrated light bar system.
- Selecting modules without an internal XMP profile causes the system to default to the standard JEDEC speed which may be lower than the rated 3200 MHz.
- Installing 2 identical modules ensures symmetrical data interleaving to optimize the communication speed between the processor and the system memory.
