ASUS ROG G712LW-EV047 RAM upgrade specifications
The ASUS ROG Strix G712LW-EV047 gaming laptop features DDR4-SDRAM memory upgrade capabilities with 2 SO-DIMM slots supporting a maximum RAM capacity of 32 GB. Compatible memory modules operate at 3200 MHz frequency specifications. The upgrade configuration allows installation of matched pairs in SO-DIMM form factor to enhance system performance and multitasking capabilities.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 16 January 2021 |
Additional Notes
- Dual channel memory architecture requires installing matching pairs of modules to achieve maximum theoretical memory bandwidth for the ASUS ROG G712LW-EV047.
- Maximum capacity limitations imply that 32 GB is the hardware ceiling, meaning 64 GB kits will likely fail to initialize or result in system instability.
- The presence of 2 physical slots necessitates the removal of existing modules to reach the maximum supported capacity as no additional expansion headers exist.
- Integration of 3200 MHz modules into a system currently using lower clock speeds will result in the faster hardware downclocking to match the slowest active module.
- Physical installation requires standard 260 pin SO-DIMM hardware, as desktop size DIMM modules are incompatible with this laptop chassis.
- Utilizing memory with aggressive CAS latency timings may require BIOS adjustments to ensure stability, though many laptop motherboards lock these parameters to JEDEC standards.
- Upgrading to the maximum memory limit reduces reliance on the Windows page file, which extends the operational lifespan of the primary solid state drive by decreasing write cycles.
