ASUS ROG GL503VM-GZ083T RAM upgrade specifications
The ASUS ROG Strix GL503VM-GZ083T laptop features 2x SO-DIMM memory slots supporting DDR4-SDRAM upgrade specifications. Maximum RAM capacity reaches 32 GB total, with compatible modules operating at 2400 MHz frequency. The SO-DIMM form factor enables memory upgrades for enhanced multitasking and performance. Specifications indicate dual-slot configuration for RAM expansion, allowing users to configure memory capacity according to workload requirements up to the 32 GB maximum threshold.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2400 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2400 (PC4-19200) |
| Bandwidth | 19.2 GB/s |
| Laptop Release date | 16 March 2018 |
Additional Notes
- Storage of high-density modules is limited to 16 GB per slot due to the internal architecture of the ASUS ROG GL503VM-GZ083T motherboard.
- The dual-slot configuration allows for synchronous memory addressing which doubles the theoretical bandwidth compared to single-channel operation.
- Installing modules with frequencies higher than 2400 MHz results in automatic downclocking to match the system bus limitations.
- The SO-DIMM form factor requires 260-pin modules and excludes the use of desktop-grade DIMM hardware.
- Latency timings should remain consistent across both slots to prevent system instability or boot failures during POST.
- Accessing the memory slots typically involves removing the base panel which may require specific toolsets for non-destructive entry.
- Mixing different brands of RAM can lead to compatibility issues even if the clock speeds match the native hardware frequency.
- Total memory capacity is capped at 32 GB because the controller cannot address the addressing space of 32 GB individual sticks.
