ASUS ROG GL503VS-EI038T RAM upgrade specifications
ASUS ROG Strix GL503VS-EI038T laptop compatible memory upgrade specifications include DDR4-SDRAM modules in SO-DIMM form factor. The device features 2 memory slots supporting maximum RAM capacity of 32 GB total. Upgrade specifications require DDR4 modules operating at 2400 MHz frequency. Compatible memory upgrades must match DDR4-SDRAM type and SO-DIMM physical specifications for proper installation in available slots.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2400 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2400 (PC4-19200) |
| Bandwidth | 19.2 GB/s |
| Laptop Release date | 06 March 2018 |
Additional Notes
- Dual channel memory architecture requires installing matched pairs of modules to maximize bandwidth for the integrated memory controller.
- Physical replacement of internal components necessitates the removal of the bottom chassis cover which exposes the cooling solution and internal battery connector.
- Mixing modules with different CAS latency ratings results in the system defaulting to the slowest shared timing profile to maintain stability.
- The 2400 MHz clock speed constitutes a performance ceiling as the motherboard chipset lacks support for higher frequency XMP profiles or overclocking.
- The 32 GB capacity limit is determined by the BIOS and hardware addressing constraints rather than the physical size of the SO-DIMM modules.
- Usage of high density 16 GB modules per slot is required to reach the maximum supported memory configuration.
- Lack of soldered memory provides a fully serviceable upgrade path for both available memory banks.
- Voltage requirements for the DDR4 standard must be 1.2V to ensure compatibility with the power delivery system of the motherboard.
