ASUS ROG GL703GM-E5108T RAM upgrade specifications
ASUS ROG Strix GL703GM-E5108T memory upgrade specifications indicate DDR4-SDRAM compatible RAM with two SO-DIMM slots available for expansion. Maximum supported memory capacity reaches 32 GB total. The laptop specifications support memory modules operating at 2666 MHz frequency. Upgrade compatibility requires DDR4-SDRAM SO-DIMM form factor modules meeting these technical specifications for proper installation and operation.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 2666 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-2666 (PC4-21328) |
| Bandwidth | 21.3 GB/s |
| Laptop Release date | 10 September 2019 |
Additional Notes
- Dual channel architecture requires matching memory modules in both slots to hit peak memory bandwidth and prevent data processing latencies.
- The 32 GB ceiling is reached by installing two 16 GB modules as the 2 SO-DIMM slots do not support higher density 32 GB individual sticks.
- Installing memory with frequencies exceeding 2666 MHz results in automatic downclocking to match the motherboard firmware limitations.
- The physical SO-DIMM layout provides for tool-less module swapping once the bottom chassis panel of the ASUS ROG GL703GM-E5108T is removed.
- Legacy DDR3 or DDR3L hardware is physically incompatible with these slots due to different notch positions and voltage requirements.
- Upgrading to the maximum capacity reduces swap file reliance on the primary storage drive which extends the lifespan of solid state components.
- Maintenance of the factory warranty usually requires using non-ECC unbuffered memory modules during any hardware expansion.
