ASUS ROG GX650PY-NM006W RAM upgrade specifications
The ASUS ROG Zephyrus Duo 16 GX650PY-NM006W features DDR5-SDRAM memory upgrade specifications with 2x SO-DIMM slots supporting a maximum capacity of 64 GB. Compatible memory modules operate at 4800 MHz frequency and utilize the SO-DIMM form factor. The laptop specifications accommodate DDR5 memory upgrades for enhanced system performance and multitasking capabilities.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
| Laptop Release date | 27 January 2023 |
Additional Notes
- Dual slot architecture facilitates symmetrical dual channel memory operation for increased bandwidth over single module configurations.
- The hardware lacks soldered memory components allowing for the total replacement of factory modules to reach maximum capacity.
- Utilizing modules with speeds exceeding 4800 MHz results in downclocking to the processor memory controller limit.
- Physical installation requires 262 pin small outline modules compatible with the ASUS ROG GX650PY-NM006W internal chassis clearance.
- Maximum capacity dictates a ceiling of 32 GB per individual slot using high density non ECC memory kits.
- Voltage requirements for DDR5 standard must be strictly followed to prevent thermal throttling or motherboard power delivery failure.
- Latency performance depends on the CAS timing of the secondary market modules which must match or exceed original specifications for system stability.
- Accessing the SO-DIMM slots involves removing the base panel which necessitates adherence to static discharge protocols to protect integrated circuit integrity.
