ASUS ROG GA401IU-HA134T RAM upgrade specifications
ASUS ROG Zephyrus G14 GA401IU-HA134T specifications indicate DDR4-SDRAM memory upgrade capacity of 24 GB maximum. The laptop contains one upgradeable SO-DIMM slot compatible with DDR4 modules operating at 3200 MHz frequency. The device features on-board memory combined with the single expandable SO-DIMM slot for RAM upgrade configuration. Specifications confirm maximum compatible memory capacity and upgrade slot availability for this specific model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 1x SO-DIMM |
| Form factor | On-board + SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 24 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 22 January 2021 |
Additional Notes
- The presence of on board memory indicates that 8 GB is permanently soldered to the motherboard of the ASUS ROG GA401IU-HA134T and cannot be removed or replaced.
- The single available expansion slot restricts memory configurations to a maximum of one 16 GB module to reach the total supported ceiling.
- Dual channel performance is only active for the specific capacity where the expansion module matches the soldered memory size.
- Any capacity added to the SO-DIMM slot exceeding the internal 8 GB will operate in single channel mode for the remaining address space.
- Replacing or adding hardware only requires access to one physical socket which simplifies the installation process compared to dual slot motherboards.
- Synchronized data transfer speeds require the installation of a 3200 MHz module to prevent the system from downclocking to the lowest common denominator.
- The total capacity ceiling of 24 GB limits the overhead available for heavy virtualization or memory intensive professional workloads.
