ASUS ROG GA402RJ-L4044W RAM upgrade specifications
ASUS ROG Zephyrus G14 GA402RJ-L4044W laptop memory upgrade specifications indicate DDR5-SDRAM memory compatibility. The device features 1x SO-DIMM slot for RAM expansion, with maximum supported capacity of 24 GB total memory. Compatible upgrade modules operate at 4800 MHz frequency. The system utilizes a hybrid memory configuration combining on-board and SO-DIMM form factor modules. Specifications confirm RAM upgrade compatibility with DDR5 standards for this ROG gaming laptop model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 1x SO-DIMM |
| Form factor | On-board + SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 24 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
| Laptop Release date | 28 November 2021 |
Additional Notes
- The presence of on-board memory means a portion of the system RAM is non-removable and soldered directly to the motherboard.
- Upgrading the ASUS ROG GA402RJ-L4044W requires matching the 4800 MHz frequency of the soldered module to prevent the system from downclocking to a lower common speed.
- Dual-channel memory performance is only active for the capacity where the SO-DIMM and soldered RAM match in size, while any excess capacity operates in single-channel mode.
- The single available SO-DIMM slot acts as the exclusive hardware interface for physical memory expansion.
- Latency timings are dictated by the slower of the two memory banks, necessitating compatible CAS latency ratings to ensure system stability.
- The 24 GB maximum limit indicates that the firmware or hardware architecture restricts the density of the module compatible with the single expansion slot.
- Asynchronous memory configurations resulting from uneven module sizes can lead to bandwidth bottlenecks in memory-intensive applications or integrated graphics tasks.
