ASUS ROG GU603ZE-LS001W RAM upgrade specifications
ASUS ROG Zephyrus M16 GU603ZE-LS001W laptop features DDR5-SDRAM memory upgrade specifications with one SO-DIMM slot available for expansion. The system supports maximum memory capacity of 40 GB through compatible DDR5 modules operating at 4800 MHz frequency. Memory configuration consists of on-board soldered RAM plus single expandable SO-DIMM slot. Upgrade specifications indicate DDR5-SDRAM compatibility for enhanced performance and multitasking capabilities on this gaming laptop model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 1x SO-DIMM |
| Form factor | On-board + SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 40 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
| Laptop Release date | 13 January 2022 |
Additional Notes
- The asymmetrical memory configuration causes the system to run in flex mode where only 16 GB of the total capacity operates at full dual channel bandwidth.
- A portion of the volatile memory is soldered directly to the motherboard and cannot be replaced or repaired in the event of a chip failure.
- Upgrading the single available expansion slot in the ASUS ROG GU603ZE-LS001W requires a 32 GB module to reach the maximum supported ceiling.
- The lack of a second SO-DIMM slot prevents the use of matched pairs for synchronous high speed data transfers across the entire memory pool.
- System stability depends on selecting a module that matches the pre-installed on-board voltage and timing parameters to avoid downclocking or boot cycles.
- Installing a module with a frequency higher than 4800 MHz results in an automatic speed reduction to match the fixed speed of the soldered memory chips.
- Internal access for hardware modification requires the removal of the chassis base plate which may expose sensitive thermal components to static discharge.
