ASUS ROG GU604VZ-NM038X RAM upgrade specifications
The ASUS ROG Zephyrus M16 GU604VZ-NM038X laptop features two SO-DIMM memory slots supporting DDR5-SDRAM modules at 4800 MHz. The upgrade specifications indicate a maximum RAM capacity of 64 GB, enabling users to expand the memory configuration for enhanced multitasking and performance. Compatible memory upgrades utilize the SO-DIMM form factor standard for this gaming laptop model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 64 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
| Laptop Release date | 19 March 2023 |
Additional Notes
- The presence of 2 SO-DIMM slots confirms that the system maintains a dual-channel memory architecture for improved bandwidth in CPU-intensive tasks.
- Total memory capacity reaches its architectural limit at 64 GB by utilizing 2 32 GB modules, which requires the replacement of any factory-installed hardware.
- Using DDR5-4800 MHz modules in the ASUS ROG GU604VZ-NM038X ensures synchronization with the memory controller to prevent downclocking or stability issues during peak voltage loads.
- Physical installation requires standard small outline modules because the chassis height does not accommodate desktop-sized DIMMs or oversized heat spreaders.
- The absence of soldered memory on the motherboard allows for a complete hardware refresh if a single module fails, avoiding a full logic board replacement.
- Latency performance depends on matching the CAS timing of both installed sticks to ensure the motherboard does not default to the slowest common denominator.
- Upgrading to the maximum theoretical capacity involves a potential increase in heat dissipation within the memory bank area during sustained rendering or gaming sessions.
