ASUS ROG GX701LV-HG016T RAM upgrade specifications

ASUS ROG Zephyrus S GX701LV-HG016T RAM upgrade specifications include DDR4-SDRAM memory operating at 2933 MHz. The laptop features one SO-DIMM slot for memory expansion, with maximum RAM capacity of 32 GB. The memory configuration consists of on-board and SO-DIMM modules. Compatible upgrades support DDR4 memory modules in SO-DIMM form factor for additional system memory capacity.

Additional Notes

• The presence of a single SO-DIMM slot combined with soldered memory creates an asynchronous dual channel configuration if the expansion module capacity exceeds the on-board allotment.
• The ASUS ROG GX701LV-HG016T memory architecture limits total capacity increases because the soldered portion cannot be removed or replaced during an upgrade.
• Installing a module with a frequency higher than 2933 MHz results in automatic downclocking to match the hardcoded speed of the on-board chips.
• Memory latency and timings will default to the highest common denominator between the fixed internal memory and the user-installed stick to maintain system stability.
• Achieving the 32 GB maximum requires a specific 16 GB or 24 GB module depending on the factory-soldered base capacity of the specific motherboard revision.
• The hardware design restricts future maintenance as a failure in the on-board memory bank necessitates a full motherboard replacement rather than a simple component swap.
• Thermals during high-load tasks can be affected by the proximity of the expansion slot to the soldered memory chips and the shared cooling assembly for the processor.
