ASUS TUF Dash FX517ZE-HN043 RAM upgrade specifications
The ASUS TUF Dash F15 FX517ZE-HN043 laptop features dual SO-DIMM memory slots supporting DDR5-SDRAM upgrades. Maximum RAM capacity reaches 32 GB with compatible modules operating at 4800 MHz frequency. Memory upgrade specifications indicate two slots available for DDR5 expansion, enabling users to enhance system performance through RAM replacement or addition.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
| Laptop Release date | 28 March 2022 |
Additional Notes
- The presence of 2 SO-DIMM slots confirms the hardware supports dual-channel memory architecture for improved bandwidth in multi-threaded applications.
- Upgrading the ASUS TUF Dash FX517ZE-HN043 requires total module replacement if both slots are occupied by 8 GB or 16 GB units to reach the 32 GB threshold.
- Installing memory modules with speeds exceeding 4800 MHz results in automatic downclocking to match the motherboard firmware ceiling.
- Low voltage operation inherent to DDR5 reduces thermal output within the chassis compared to legacy DDR4 standards.
- Integrated power management circuits on the memory modules shift voltage regulation tasks away from the motherboard to the RAM sticks.
- On-die Error Correction Code technology within the chips provides enhanced system stability during high-load processing by correcting single-bit errors internally.
- Physical access to the memory slots requires removal of the bottom chassis panel which may involve various screw lengths and plastic retention clips.
- Mixing modules with different latencies or densities can trigger compatibility fallback modes or boot failures despite identical clock speeds.
