ASUS TUF Dash FX517ZM-HN073W RAM upgrade specifications
ASUS TUF Dash F15 FX517ZM-HN073W laptop RAM upgrade specifications indicate two SO-DIMM memory slots supporting DDR5-SDRAM modules. Maximum memory capacity reaches 32 GB total. Compatible DDR5 memory operates at 4800 MHz frequency. Upgradeable configuration allows users to replace or add modules within SO-DIMM form factor constraints. Complete memory specifications detail slot availability and supported DDR5 standards for this TUF Dash series gaming laptop model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
| Laptop Release date | 21 January 2022 |
Additional Notes
- The dual channel architecture requires symmetrical module pairs to achieve full memory bandwidth and prevent bottlenecks in integrated graphics performance.
- Utilizing both SO-DIMM slots on the ASUS TUF Dash FX517ZM-HN073W ensures the processor accesses the wider 128 bit memory bus characteristic of DDR5 technology.
- The transition to DDR5 lowers operating voltage compared to previous generations, which reduces secondary heat generation within the compact chassis during high load scenarios.
- Installing modules with speeds exceeding 4800 MHz will result in automatic downclocking to remain within the firmware defined frequency ceiling.
- Capacity expansions are restricted to 16 GB per slot due to the specialized power management integrated circuits found on individual DDR5 sticks.
- Hardware upgrades require disconnecting the internal battery bridge to prevent short circuits since DDR5 chips maintain a residual charge longer than older standards.
- Latency performance depends on the CAS timing compatibility between the factory installed unit and any aftermarket addition to avoid system instability.
