ASUS TUF Dash FX517ZM-HN073W-BE RAM upgrade specifications
ASUS TUF Dash F15 model FX517ZM-HN073W-BE features two SO-DIMM memory slots supporting DDR5-SDRAM specifications. The laptop accommodates maximum RAM capacity of 32 GB with DDR5-4800 MHz frequency. Memory upgrade slots are compatible with standard SO-DIMM form factor modules. Current specifications allow for dual-channel memory configuration on this gaming laptop model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR5-SDRAM |
| Frequency | 4800 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.1V |
| Number of pins | 262-pin |
| Interface | PC5 |
| PC Speed Rating | PC5-4800 (PC5-38400) |
| Bandwidth | 38.4 GB/s |
| Laptop Release date | 10 January 2022 |
Additional Notes
- The ASUS TUF Dash FX517ZM-HN073W-BE uses SO-DIMM slots, which means only laptop-specific memory modules will fit; desktop DDR5 DIMMs cannot be installed regardless of capacity matching.
- DDR5-4800 MHz memory operates at the JEDEC standard speed for this generation, but third-party modules rated above this frequency will downclock to 4800 MHz due to BIOS limitations, eliminating any performance premium from higher-speed kits.
- With 2 SO-DIMM slots and a 32 GB ceiling, maximum capacity is only achievable with 2x16 GB modules; single-slot upgrades will leave one slot empty and prevent symmetric dual-channel operation unless both slots contain populated DIMMs.
- Factory-installed memory configuration cannot be determined from specifications alone; upgrading only one slot may result in asymmetric channel performance if the original module occupies a different slot than the new module.
- SO-DIMM modules require careful insertion at a 45-degree angle followed by downward pressure until retention clips engage; improper seating is a common installation failure that produces no error messages but causes system instability.
- Memory upgrades on this model carry no inherent warranty risk if performed by the end user, as DDR5 SO-DIMM replacement falls within standard user-serviceable maintenance on modern ASUS gaming laptops.
- The 32 GB maximum constraint limits multitasking capacity for applications like 3D rendering, virtual machines, or professional video editing; users approaching memory saturation cannot resolve it through internal upgrades beyond this ceiling.
