ASUS TUF Gaming FA506QM-HN005 RAM upgrade specifications
The ASUS TUF Gaming A15 FA506QM-HN005 features two SO-DIMM slots for DDR4-SDRAM memory upgrades. Maximum supported RAM capacity reaches 32 GB, with compatible modules operating at 3200 MHz frequency. The laptop specifications allow for memory expansion using standard SO-DIMM form factor modules. Current and future DDR4 memory upgrades maintain compatibility with the FA506QM-HN005 configuration, supporting dual-channel memory architecture for enhanced system performance.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 20 January 2021 |
Additional Notes
- Dual channel memory architecture requires installing matching pairs of modules to maximize the available data bus bandwidth for the processor.
- The absence of soldered memory on the ASUS TUF Gaming FA506QM-HN005 motherboard allows for the full replacement of both factory modules if lower latency timings are required.
- Operating at the maximum supported frequency requires modules to feature a built-in JEDEC profile for 3200 MHz to avoid downclocking on systems without XMP BIOS support.
- Future capacity expansion is restricted to 16 GB per slot due to the physical limitations of the chipset memory controller.
- High density 1Rx16 modules may result in reduced performance compared to 1Rx8 or 2Rx8 alternatives during heavy gaming workloads.
- Accessing the internal hardware for upgrades involves removing the bottom chassis panel which necessitates a non-marring pry tool to avoid damaging the plastic perimeter clips.
- Using 1.2V low voltage modules is necessary to ensure electrical compatibility and maintain thermal efficiency within the compact enclosure.
