ASUS TUF Gaming FA506QM-HN008T RAM upgrade specifications
ASUS TUF Gaming A15 FA506QM-HN008T RAM upgrade specifications detail memory compatibility and maximum capacity configurations. The laptop features 2x SO-DIMM slots supporting DDR4-SDRAM memory modules. Maximum RAM capacity reaches 32 GB total across both slots. Compatible memory operates at 3200 MHz frequency for optimal performance. SO-DIMM form factor specifications ensure proper physical fit within available upgrade slots. These specifications establish upgrade parameters for memory expansion on the FA506QM-HN008T model.
Memory Upgrade Specifications
| Specification | Value |
|---|---|
| Memory slots | 2x SO-DIMM |
| Form factor | SO-DIMM |
| Memory type | DDR4-SDRAM |
| Frequency | 3200 MHz |
| Maximum RAM | 32 GB |
| Voltage | 1.2V |
| Number of pins | 260-pin |
| Interface | PC4 |
| PC Speed Rating | PC4-3200 (PC4-25600) |
| Bandwidth | 25.6 GB/s |
| Laptop Release date | 01 February 2021 |
Additional Notes
- The ASUS TUF Gaming FA506QM-HN008T accommodates only 2 SO-DIMM slots, which means the system operates as a dual-channel configuration. Upgrading requires replacing both existing modules simultaneously to achieve the 32 GB maximum; adding a single module will not expand capacity.
- DDR4-3200 MHz is the validated frequency ceiling for this platform. Modules rated above 3200 MHz may post but lack manufacturer support and can introduce instability or boot failures, particularly when combined with BIOS settings for maximum performance.
- SO-DIMM memory requires disassembly of the bottom panel or keyboard deck on gaming laptops of this class. Installation typically demands removal of the battery and thermal shrouding, extending downtime and increasing handling risk to surrounding components if proper procedures are not followed.
- The 32 GB upgrade ceiling constrains futureproofing for memory-intensive workloads such as 4K video editing, large virtual machines, or simultaneous high-poly 3D rendering. The non-upgradeable architecture prevents the system from scaling beyond this threshold without full system replacement.
- Purchasing third-party DDR4-3200 SO-DIMM modules voids coverage from memory-related warranty claims; only ASUS-supplied or explicitly validated components maintain OEM support, requiring documentation retention for any failure disputes.
- Latency characteristics of replacement modules affect gaming frame consistency more than raw capacity. Timings of CAS 16 or higher may introduce frame variance compared to OEM modules, particularly in esports titles running above 144 fps.
